View big picture

  Item No.: 52,53 series Double row Angular Contact Ball Bearings

Boundary dimensions(mm)

Basic load ratings(kN)

Limiting speeds(rpm)

Mass(Kg)

Bearing Number

d

D

B

rs min

Cr

Cor

Grease

Oil

(Approx.)

10

30

14.3

0.6

6.95

3.8

14,000

19,000

0.049

5200

12

32

15.9

0.6

9.15

5.05

13,000

17,000

0.057

5201

15

35

15.9

0.6

10

6.05

11,000

15,000

0.064

5202

17

40

17.5

0.6

12.8

7.9

9,900

13,000

0.096

5203

20

47

20.6

1

19

12.1

8,800

12,000

0.153

5204

25

52

20.6

1

20.6

14.3

7,300

9,800

0.175

5205

30

62

23.8

1

28.6

20.4

6,300

8,400

0.286

5206

35

72

27

1.1

38

27.8

5,500

7,400

0.436

5207

40

80

30.2

1.1

42.5

32.5

4,900

6,600

0.59

5208

45

85

30.2

1.1

48

37

4,400

5,900

0.64

5209

50

90

30.2

1.1

51

42

4,000

5,300

0.689

5210

55

100

33.3

1.5

63

53

3,600

4,900

0.986

5211

60

110

36.5

1.5

71.5

58.5

3,400

4,500

1.27

5212

65

120

38.1

1.5

83.5

72.5

3,100

4,200

1.57

5213

70

125

39.7

1.5

90.5

79.5

2,900

3,900

1.8

5214

75

130

41.3

1.5

90

80.5

2,700

3,600

1.9

5215

80

140

44.4

2

106

95.5

2,500

3,400

2.39

5216

85

150

49.2

2

112

106

2,400

3,200

3.06

5217

90

160

52.4

2

140

129

2,200

3,000

3.73

5218

95

170

55.6

2.1

159

148

2,100

2,800

4.86

5219

100

180

60.3

2.1

178

167

2,000

2,700

5.94

5220

15

42

19

1

17.2

10.1

9,900

13,000

0.132

5302

17

47

22.2

1

20.4

12.1

9,000

12,000

0.181

5303

20

52

22.2

1.1

20.6

12.7

8,000

11,000

0.217

5304

25

62

25.4

1.1

30.5

20.5

6,700

8,900

0.362

5305

30

72

30.2

1.1

39.5

27.5

5,700

7,600

0.553

5306

35

80

34.9

1.5

49.5

35

5,000

6,600

0.766

5307

40

90

36.5

1.5

60.5

44

4,400

5,900

1.01

5308

45

100

39.7

1.5

72.5

54

4,000

5,300

1.34

5309

50

110

44.4

2

85.5

64.5

3,600

4,800

1.81

5310

55

120

49.2

2

106

82

3,300

4,400

2.32

5311

60

130

54

2.1

122

95.5

3,000

4,000

3.05

5312

65

140

58.7

2.1

138

109

2,800

3,700

3.96

5313

70

150

63.5

2.1

155

125

2,600

3,500

4.74

5314

75

160

68.3

2.1

168

141

2,400

3,200

5.65

5315
