View big picture

  Item No.: GAC...T Series Angular contact spherical plain bearings

Boundary dimensions(mm)

Mass

Bearing Number

d

D

B

C

T

dk

S

rs,r1s

a

Kg

Part No.

min

25

47

15

14

15

42

0.6

1

2.5

0.148

GAC25T

28

52

16

15

16

47

1

1

2

0.186

GAC28T

30

55

17

15

17

49.5

1.3

1

4.5

0.208

GAC30T

32

58

17

16

17

52

2

1

2

0.241

GAC32T

35

62

18

16

18

55.5

2.1

1

4

0.268

GAC35T

40

68

19

17

19

62

2.8

1

3.5

0.327

GAC40T

45

75

20

18

20

68.5

3.5

1

3

0.416

GAC45T

50

80

20

19

20

74

4.3

1

1.5

0.455

GAC50T

55

90

23

20

23

82

5

1.1

4

0.645

GAC55T

60

95

23

21

23

88.5

5.7

1.1

2.5

0.714

GAC60T

65

100

23

22

23

93.5

6.5

1.1

1

0.759

GAC65T

70

110

25

23

25

102

7.2

1.1

2

1.04

GAC70T

75

115

25

24

25

107

7.9

1.1

1

1.12

GAC75T

80

125

29

25.5

29

115

8.6

1.1

3.5

1.54

GAC80T

85

130

29

26.5

29

122

9.4

1.1

2

1.61

GAC85T

90

140

32

28

32

128.5

10.1

1.5

3.5

2.09

GAC90T

95

145

32

29.5

32

135

10.8

1.5

2

2.22

GAC95T

100

150

32

31

32

141

11.6

1.5

0.5

2.34

GAC100T

105

160

35

32.5

35

148

12.3

2

2

2.93

GAC105T

110

170

38

34

38

155

13

2

3

3.68

GAC110T

120

180

38

37

38

168

14.5

2

0.5

3.97

GAC120T

130

200

45

43

45

188

18

2.5

1

5.92

GAC130T

140

210

45

43

45

198

19

2.5

1

6.33

GAC140T

150

225

48

46

48

211

20

3

1

8.01

GAC150T

160

240

51

49

51

225

20

3

1

9.42

GAC160T

170

260

57

55

57

246

21

3

1

12.3

GAC170T

180

280

64

61

64

260

21

3

1

17.4

GAC180T

190

290

64

62

64

275

26

3

0.5

18.2

GAC190T

200

310

70

66

70

290

26

3

1.5

22.5

GAC200T
