View big picture

  Item No.: GAC...S;GACZ...S Angular contact spherical plain bearings

Boundary dimensions(mm)

Mass

Bearing Number

d

D

B

C

T

dk

S

A

rs,r1s

a

Kg

min

25

47

15

14

15

42

0.6

7.5

1

2.5

0.148

GAC25S

28

52

16

15

16

47

1

8

1

2

0.186

GAC28S

30

55

17

15

17

49.5

1.3

8.5

1

4.5

0.208

GAC30S

32

58

17

16

17

52

2

8.5

1

2

0.241

GAC32S

35

62

18

16

18

55.5

2.1

9

1

4

0.268

GAC35S

40

68

19

17

19

62

2.8

9.5

1

3.5

0.327

GAC40S

45

75

20

18

20

68.5

3.5

10

1

3

0.416

GAC45S

50

80

20

19

20

74

4.3

10

1

1.5

0.455

GAC50S

55

90

23

20

23

82

5

11.5

1.1

4

0.645

GAC55S

60

95

23

21

23

88.5

5.7

11.5

1.1

2.5

0.714

GAC60S

65

100

23

22

23

93.5

6.5

11.5

1.1

1

0.759

GAC65S

70

110

25

23

25

102

7.2

12.5

1.1

2

1.04

GAC70S

75

115

25

24

25

107

7.9

12.5

1.1

1

1.12

GAC75S

80

125

29

25.5

29

115

8.6

14.5

1.1

3.5

1.54

GAC80S

85

130

29

26.5

29

122

9.4

14.5

1.1

2

1.61

GAC85S

90

140

32

28

32

128.5

10.1

16

1.5

3.5

2.09

GAC90S

95

145

32

29.5

32

135

10.8

16

1.5

2

2.22

GAC95S

100

150

32

31

32

141

11.6

16

1.5

0.5

2.34

GAC100S

105

160

35

32.5

35

148

12.3

17.5

2

2

2.93

GAC105S

110

170

38

34

38

155

13

19

2

3

3.68

GAC110S

120

180

38

37

38

168

14.5

19

2

0.5

3.97

GAC120S

130

200

45

43

45

188

18

19

2.5

1

5.92

GAC130S

140

210

45

43

45

198

19

19

2.5

1

6.33

GAC140S

150

225

48

46

48

211

20

20.5

3

1

8.01

GAC150S

160

240

51

49

51

225

20

22

3

1

9.42

GAC160S

170

260

57

55

57

246

21

27

3

1

12.3

GAC170S

180

280

64

61

64

260

21

28

3

1

17.4

GAC180S

190

290

64

62

64

275

26

30

3

0.5

18.2

GAC190S

200

310

70

66

70

290

26

30

3

1.5

22.5

GAC200S

12.7

22.2

6.86

4.83

7.62

18.26

1.3

2.39

0.51

7

0.013

GACZ12S

15.875

27

8.64

6.35

9.4

22.83

1.48

2.77

0.76

6

0.025

GACZ15S

19.05

31.8

10.4

7.87

11.2

27.43

1.79

3.18

1

6

0.038

GACZ19S

22.225

36.5

12.2

9.65

13.2

31.95

2.02

4.37

2

5.5

0.049

GACZ22S

25.4

41.3

14

11.18

15.2

36.5

2.54

5.16

2

6

0.085

GACZ25S

31.75

50.8

17.8

13.97

18.8

45.59

3.36

5.94

2

6

0.159

GACZ31S

34.925

55.6

19.6

15.24

21.3

49.2

3.69

7.14

2.54

4

0.213

GACZ34S

38.1

61.9

21.3

16.76

23.1

54.74

3.93

7.92

2.54

5.5

0.301

GACZ38S

44.45

71.4

24.9

20.07

27.2

63.88

4.72

8.33

2.54

6

0.458

GACZ44S

50.8

81

28.7

23.37

31.2

73.02

5.51

9.52

3.56

5.5

0.671

GACZ50S

57.15

90.5

32.3

26.67

35.3

82.17

6.18

11.5

3.56

5.5

0.948

GACZ57S

63.5

100

36.1

29.97

39.1

91.19

6.79

12.7

3.56

5

1.13

GACZ63S

69.85

111

39.6

32.38

43.2

100.3

7.46

13.1

4.6

5

1.75

GACZ69S

76.2

121

43.4

35.69

47.2

109.5

8.17

14.7

4.6

5

2.28

GACZ76S

82.55

130

47.2

39.24

51.6

118.7

9.04

16.7

4.6

5

2.89

GACZ82S

88.9

140

50.8

42.54

55.4

128

9.51

17.9

4.6

5

3.57

GACZ88S

95.25

149

54.6

45.85

59.4

136.9

10.1

19.4

4.6

4.5

4.35

GACZ95S

101.6

159

58.4

49.15

63.5

146.1

10.4

19.8

4.6

4.5

5.26

GACZ101S

114.3

178

65.8

55.75

71.1

164.5

12.4

22.2

4.6

4.5

7.76

GACZ114S

127

197

73.2

62.36

79.5

182.6

13.9

25.4

4.6

4.5

11.07

GACZ127S
