View big picture

  Item No.: GX...S Spherical plain thrust bearings

Boundary dimensions(mm)

Mass

Bearing Number

d

D

B

C

H

dk

S

d1 max

D1 min

A

rs,r1s min

a

kg

10

30

7.5

7

9.5

32

7

27.5

15.5

3

0.6

5

0.036

GX10S

12

35

9.5

9.3

13

38

8

32

18

4

0.6

5

0.072

GX12S

15

42

11

10.8

15

46

10

39

22.5

5

0.6

6

0.108

GX15S

17

47

11.8

11.2

16

52

11

43.5

27

5

0.6

4

0.137

GX17S

20

55

14.5

13.8

20

60

12.5

50

31

6

1

5

0.246

GX20S

25

62

16.5

16.7

22.5

68

14

58.5

34.5

6

1

5

0.415

GX25S

30

75

19

19

26

82

17.5

70

42

8

1

5

0.614

GX30S

35

90

22

20.7

28

98

22

84

50.5

8

1

5

0.973

GX35S

40

105

27

21.5

32

114

24.5

97

59

9

1

6

1.59

GX40S

45

120

31

25.5

36.5

128

27.5

110

67

11

1

6

2.24

GX45S

50

130

33

30.5

42.5

139

30

120

70

10

1

6

3.14

GX50S

60

150

37

34

45

160

35

140

84

12.5

1

6

4.63

GX60S

70

160

42

36.5

50

176

35

153

94.5

13.5

1

3

5.37

GX70S

80

180

43.5

38

50

197

42.5

172

107.5

14.5

1

4

6.91

GX80S

100

210

51

46

59

222

45

198

127

15

1.1

4

10.9

GX100S

120

230

53.5

50

64

250

52.5

220

145

16.5

1.1

3

13.9

GX120S

140

260

61

54

72

274

52.5

243

177

23

1.5

3

18.1

GX140S

160

290

66

58

77

313

65

271

200

23

1.5

2

23.2

GX160S

180

320

74

62

86

340

67.5

299

225

26

1.5

4

30.9

GX180S

200

340

80

66

87

365

70

320

247

27

1.5

1

34.2

GX200S
