View big picture

  Item No.: SA...C/E/ES/ET-2RS/SABP...S/SAJK...C Rod End

Boundary dimensions(mm)

Mass

Bearing Number

d

B

dk

C1

d2

G

h

l1

l2

rs

a

Kg

max

max

6g

min

max

min

5

6

10

4.5

21

M5

36

16

46.5

0.3

13

0.011

SA5C

6

6

10

4.5

21

M6

36

16

46.5

0.3

13

0.013

SA6C

8

8

13

6.5

24

M8

42

21

54

0.3

15

0.026

SA8C

10

9

16

7.5

29

M10

48

26

62.5

0.3

12

0.044

SA10C

12

10

18

8.5

34

M12

54

28

71

0.3

10

0.066

SA12C

15

12

22

10.5

40

M14

63

34

83

0.3

8

0.12

SA15C

17

14

25

11.5

46

M16

69

36

92

0.3

10

0.17

SA17C

20

16

29

13.5

53

M20X1.5

78

43

105

0.3

9

0.28

SA20C

25

20

36

18

64

M24X2

94

53

126

0.6

7

0.51

SA25C

30

22

41

20

73

M30X2

110

65

147

0.6

6

0.84

SA30C

5

6

10

4.5

21

M5

36

16

46.5

0.3

13

0.011

SA5E

6

6

10

4.5

21

M6

36

16

46.5

0.3

13

0.013

SA6E

8

8

13

6.5

24

M8

42

21

54

0.3

15

0.026

SA8E

10

9

16

7.5

29

M10

48

26

62.5

0.3

12

0.044

SA10E

12

10

18

8.5

34

M12

54

28

71

0.3

10

0.066

SA12E

15

12

22

10.5

40

M14

63

34

83

0.3

8

0.121

SA15ES

17

14

25

11.5

46

M16

69

36

92

0.3

10

0.172

SA17ES

20

16

29

13.5

53

M20X1.5

78

43

105

0.3

9

0.283

SA20ES

25

20

36

18

64

M24X2

94

53

126

0.6

7

0.504

SA25ES

30

22

41

20

73

M30X2

110

65

147

0.6

6

0.835

SA30ES

35

25

47

22

82

M36X3

140

82

181

0.6

6

1.41

SA35ES

40

28

53

24

92

M39X3

150

86

196

0.6

7

1.86

SA40ES

45

32

60

28

102

M42X3

163

92

214

0.6

7

2.57

SA45ES

50

35

66

31

112

M45X3

185

104

241

0.6

6

3.58

SA50ES

60

44

80

39

135

M52X3

210

115

278

1

6

5.73

SA60ES

70

49

92

43

160

M56X4

235

125

315

1

6

7.94

SA70ES

80

55

105

48

180

M64X4

270

140

360

1

6

12.06

SA80ES

35

25

47

22

82

M36X3

140

82

181

0.6

6

1.4

SA35ET-2RS

40

28

53

24

92

M39X3

150

86

196

0.6

7

1.8

SA40ET-2RS

45

32

60

28

102

M42X3

163

92

214

0.6

7

2.5

SA45ET-2RS

50

35

66

31

112

M45X3

185

104

241

0.6

6

3.6

SA50ET-2RS

60

44

80

39

135

M52X3

210

115

278

1

6

5.7

SA60ET-2RS

70

49

92

43

160

M56X4

235

125

315

1

6

7.9

SA70ET-2RS

80

55

105

48

180

M64X4

270

140

360

1

6

12

SA80ET-2RS

5

8

11

6

16

M5

33

20

41

0.3

13

0.016

SABP5S

6

9

13

6.75

18

M6

36

22

45

0.3

13

0.026

SABP6S

8

12

16

9

22

M8

42

25

53

0.3

14

0.044

SABP8S

10

14

19

10.5

26

M10

48

29

61

0.6

14

0.072

SABP10S

12

16

22

12

30

M12

54

33

69

0.6

13

0.108

SABP12S

14

19

25

13.5

34

M14

60

36

77

0.6

16

0.161

SABP14S

16

21

29

15

38

M16

66

40

85

0.6

15

0.225

SABP16S

18

23

32

16.5

42

M18X1.5

72

44

93

0.6

15

0.295

SABP18S

20

25

35

18

46

M20X1.5

78

47

101

0.6

15

0.382

SABP20S

22

28

38

20

50

M22X1.5

84

51

109

0.6

15

0.488

SABP22S

25

31

43

22

60

M24X2

94

57

124

0.6

15

0.749

SABP25S

28

35

48

25

66

M27X2

103

62

136

0.6

15

0.949

SABP28S

30

37

51

25

70

M30X2

110

66

145

0.6

17

1.13

SABP30S

5

8

11

7.5

18

M5

33

19

42

0.3

4

0.013

SAJK5C

6

9

13

7.5

20

M6

36

21

46

0.3

9

0.015

SAJK6C

8

12

16

9.5

24

M8

42

25

54

0.3

12

0.034

SAJK8C

10

14

19

11.5

30

M10

48

28

63

0.6

10

0.071

SAJK10C

12

16

22

12.5

34

M12

54

32

71

0.6

12

0.11

SAJK12C

14

19

25

14.5

38

M14

60

36

79

0.6

14

0.13

SAJK14C

16

21

29

15.5

42

M16

66

37

87

0.6

14

0.22

SAJK16C

18

23

32

17.5

46

M18X1.5

72

41

95

0.6

13

0.29

SAJK18C

20

25

35

18.5

50

M20X1.5

78

45

103

0.6

14

0.36

SAJK20C

22

28

38

21

56

M22X1.5

84

48

112

0.6

14

0.49

SAJK22C

25

31

43

23

60

M24X2

94

55

124

0.6

14

0.65

SAJK25C

28

35

48

26

66

M27X2

103

62

136

0.6

14

0.87

SAJK28C

30

37

51

27

70

M30X2

110

66

145

0.6

15

1.1

SAJK30C
