View big picture

  Item No.: Timing belts
Timing belt
Timing belt transmission synthesizes the stringpoins of gear drive,chain drive.It has the feature
of non-slip, Iubrication free, non-pollution,high efficiency,energy saving etc.
Characteristics
High Efficiency
Slip-Free Power Transmission
Long Service Life
Very High Abrasion Resistant
Maintenance Free Operation

T type industrial rubber timing belt

Type

Pitch

Tooth height

Belt thickness

Angle

MXL

2.032

0.51

1.14

40

XXL

3.175

0.76

1.52

50

XL

5.08

1.27

2.3

50

PLL

9.525

1.91

3.6

40

H

12.7

2.29

4.3

40

XH

22.225

6.35

11.2

40

XXH

31.75

9.53

15.7

40

T2.5

2.5

0.7

1.3

40

T5

5

1.2

2.2

40

T10

10

2.5

4.5

40

T20

20

5

8

40

AT5

5

1.2

2.7

50

AT10

10

2.5

5

50

AT20

20

5

8

50

Arc tooth industrial rubber synchronors belt

Gear code

Type

Pitch

Tooth height

Belt thickness

HTD

3M

3

1.17

2.4

5M

5

2.06

3.8

8M

8

3.36

6

14M

14

6.02

10

20M

20

8.4

13.2

STPD/STS

S2M

2

0.76

1.36

S3M

3

1.14

1.9

S4.5M

4.5

1.71

2.81

S5M

5

1.91

3.4

S8M

8

3.05

5.3

S14M

14

5.3

10.2

RPP/HPPD

RP2M

2

0.76

1.36

Rp3M

3

1.15

1.9

Rp5M

5

1.95

3.5

Rp8M

8

3.2

5.5

Rp14M

14

6

10
